MARCA FMA
RED / IR Laser & IR Illuminator
Modello PEQ LA5-A.
Colore BLACK.
Per slitte da 20mm.
Materiale polimero rinforzato.
Alimentato da batteria 1x CR123 (NON INCLUSE).
Adesivi inclusi.
Pulsante remoto incluso.
Peso 205gr.
Mode Selector PEQ LA5-A Button Switch
AH -- Keep laser on (Strong). Single Click interrupted light, double click, keep lase on. (Power 9.0 mw)
AL -- Keep laser on (Weak). Single Click interrupted light, double click, keep flashing light on. (Power 2.57 mw)
O -- Turn off
P -- Changed to Keep Flishing on (Power 0.64 mw)
IR -- Switch to IR Function
AL-IR -- (Weak light on the Right) On, Single click interrupted light, DOuble click, keep flashing light on.
DL -- IR Assist lamp On (Left) and (Right), IR assist lamp Weakly on, IR On (Weak light). Single Click interrupted light, Double click, keep flashing light on.
AH -- IR On (Strong light on the Righ), Single Click interrupted light, Double click, keep flashing light on. (Power 32.4 mw)
IH -- IR Assist lamp On (Left) and (Right), IR assist lamp Strongly on, IR On (Weak light). Single Click interrupted light, Double click, keep flashing light on.
DH -- IR Assist lamp On (Left) and (Right), IR assist lamp Strongly on, IR On (Strong light). SIngle Click interrupted light, Double click, keep flashing light on.
Led Status Indicator
COLOR INDICATION | INDICATION STATUS | STATUS |
---|---|---|
Green | Keep Light On | Open: Keep Light On |
Red | Keep Light On | Laser not activaten, Power Low |
Orange | 3 Times Orange Flashing | Mode Changed |
Automatic Shutdown after 300 second
